PRECISION LUBRICATING OIL
CERTIFIED NSF H1
FOR THE FOOD INDUSTRY
CODEX LUBRICANT FOR THE PHARMACEUTICAL INDUSTRY
COLOURLESS, WITHOUT ODOUR, TASTELESS,
WITHOUT ORGANOLEPTIC EFFECTS
TEXTILE, PACKAGING, COSMETICS
PERFUME INDUSTRIES
LUBRICATION OF TRANSMISSIONS
(INFORMATION AND POWER).
COMPATIBLE WITH ALL METALS, THERMOSETTING PLASTICS, THERMOPLASTICS, ELASTOMERS
DESCRIPTION
Fluid for the lubrication of precision mechanisms operating under low loads and at low speeds but for large numbers of cycles. Usable on all metals, plastics and elastomers. Does not stain ; odourless, tasteless.
Totally inert, chemically and biologically. Antioxidant, does not desiccate, does not rancidify.
Apolar and hydrophobic. Electrically insulating. Assembly, lubrication, demoulding and extrusion operations ; non-adhesive.
Totally water-resistant.
Food processing, textile, packaging, watchmaking, pharmaceutical and cosmetics industries.
Precision equipment: photographic, reprographic and office automation equipment.
Rails, slides, hinges, hinged joints, locks, information transmission, cams, plungers, toggle mechanisms. Industrial sewing machines. Crimping mechanisms. Screwdriving operations. Use of PE film.
FIELDS OF USE
Lubrication of Sulzer weaving looms.
Sizing of sewing thread.
Lubrication of bobbins, winding frames, thread guides.
Assembly of O-rings, dynamic or static gaskets.
Assembly of waterbox gaskets.
Lubrication of elastomers and rubbers.
Demoulding of light alloys.
Assembly of elastomers on metal cores.
Glide of tyres on conveyors.
Internal lubrication of cables.
Lubrication of Nylon rope.
Lubrication of telescopic mechanisms.
Lubrication of cams and plungers in the clock and watch industry.
Lubrication of photographic, reprographic and office automation equipment.
Die-cutting and drop forging of precision parts.
Lubrication of clamps, riveted shafts, threaded assemblies.
Fastenings, shafts, linkage, shutter guide rails, roller blinds.
Locks, hinges.
Lubrication of surgical instruments, hospital equipment.
Demoulding of compressed powders.
Manufacture of medication, encapsulation.
Demoulding of foodstuffs, rusks.
Lubrication of precision mechanisms, household appliances.
Treatment of air filters.
Protection of low voltage terminals and contacts.
Lubrication of meters, switches, relays.
Lubrication of pulleys, sheaves, zippers.
DIRECTIONS FOR USES
Shake the aerosol briefly, in an upanddown movement. Spray from a distance of 15 to 25 cm from the surfaces to be treated, depending on their dimensions.Aerosol usable in any position.
PHYSICO-CHEMICAL PROPERTIES TYPICALS
|
PHYSICAL PROPERTIES OF THE LUBRICATING OIL |
||||
|
PROPERTIES |
STANDARD or METHOD |
VALUE |
UNITS |
|
|
Appearance |
visual |
Fluid |
nm |
|
|
Colour |
Visual |
Colourless |
nm |
|
|
Scent |
Olfactory |
No smell |
nm |
|
|
Density at 20°C |
NF EN ISO 12.185 |
795 |
g/l |
|
|
Nature of solid lubricants |
- |
Without |
- |
|
|
Nature of base oil |
- |
Mineral |
- |
|
|
Kinematic Viscosity Base oil at 40°C Base oil at 100°C |
NF EN ISO 3,104 |
70 45 |
mm2/s-1 mm2/s-1 |
|
|
Sulphated ash |
NF T 60.144 |
<0.01 |
% |
|
|
Acid index (ai) |
EN 14,104 |
<0.1 |
mg(KOH)/g |
|
|
Closed-cup flash point |
NF EN 22.719 |
220 |
°C |
|
|
Self-combustion point |
ASTM E 659 |
>280 |
°C |
|
|
Freezing point |
ISO 3016 |
-28 |
°C |
|
|
Impurities > 25 µ > 75 µ > 125 µ |
FMTS 791 3005 |
0 0 0 |
number/ml number/ml number/ml |
|
|
PERFORMANCE PROPERTIES |
||||
|
PROPERTIES |
STANDARD or METHOD |
VALUE |
UNITS |
|
|
Utilisation temperature range |
- |
-20 +200 |
°C |
|
|
Copper blade corrosion 24h 100°C |
ISO 2160 |
1a |
value |
|
|
Loss by evaporation 22h at 121°C |
ASTM D 972 |
<2 |
% mass |
|
|
SHELL 4-ball test Impression diameter Weld load index |
ISO 20.623 – ASTM D 2266 |
0.8 1800 |
mm daN |
|
|
SRV test |
ASTM D 5707 |
nm |
coefficient |
|
|
Elastomer swelling test (dimensional change) |
FTM 791 |
< 0.005 |
% |
|
|
Suppression of operating noise |
FAG MMG 11 |
2 |
category |
|
|
Maximum permitted speed |
- |
0.01 |
m/s-1 |
|
|
Water wash-off resistance at 80°C |
ASTM 1264 |
-5.8 |
% |
|
|
Cold starting torque at -20°C |
ASTM D 1478-63 |
10 |
N.cm |
|
PRESENTATIONS
|
|
Aerosol 650 ml
|
Can 20 L
|
.jpg)
Product for the food industry
Using a HACCP approach or method
Analysis of dangers and critical points to control them
ISO 22 000 CODEX ALIMENTARIUS
Category NSF:
H1 lubricant: usable in food manufacturing areas. Useable as an anti-corrosion agent, non-stick for oven door seals, lubricant for materials located in potential food-contact areas.
